How to update Xhorse Condor XC-mini power supply

Xhorse released new power supply adapter with battery for Condor XC-Mini key cutting machine with which you can cut 40 keys per charge.

How to change/update Condor XC-Mini built-in power supply?

1.Remove the screws.

2.Remove the shell.

3.Rotate the little round screw to the innermost.

4.Then we need to remove the clip.Pull it out.

5.Rotate the screws on both sides,remove out the clip.

6.Use insulating tape to connect two cables together.

7.Lay down condor mini machine.Remove the screws.

8.Take out the board.Unplug the clip.

Rotate two screws to remove the cables from the PCB.

9.Here two separate yellow color cable,number 7 and 6.

10.Number 6 cable is connected to 12 on clip.

Cable 7 connects with 11. Lock the screws.

11.Put back clip to original place.

12.Next step: remove the power adapter on Condor MINI

13.Put the new power adapter.You can find new power adapter in Power Supply Adapter with Battery Kit.

Put back screws and lock it.

14.Put two yellow cables together with new power adapter cables under the clip through the hole.

15.Connect Power Adapter battery PCB.

It lists out number from 1 to 9,and 24V.

16.Connect cables to the numbers, VCC and GND. Please note the numbers must be matched.

Connect cables,as well as VCC and GND.

17.Put back PCB to condor mini.And two shells,lock the screws.

18.Now,we power on to start for test.It shows charge capacity.

19.Use old charge cable with new charge adapter,connect with power supply,it can charge power.

We can also use Car cigarette lighter cable to charge.

20.Upgrade to the built-in power supply successfully.

www.vvdishop.com

condor xc-mini condor mini

Emily پنج‌شنبه 3 خرداد 1397 ساعت 14:03

0 نظر

Jetta 2008 BCM Wiring Connection to Xhorse VVDI Prog

New test report: read VW Jetta year 2008 4th generation immo box BCM data success by using Xhorse VVDI Prog programmer & TMS370 adapter.

Solder TMS370 adapter to VVDI-Prog

Open VVDI Prog software

Select 4-Immobilizer-> VW->Jetta-IMMOBOX(–2008)

Check connection wiring diagram

Read IMMO box data

Save data.

Done.

www.vvdishop.com

http://blog.vvdishop.com/xhorse-vvdi-prog-read-jetta-2008-immo-bcm/

VVDI Prog xhorse vvdi prog

Emily چهارشنبه 2 خرداد 1397 ساعت 12:47

0 نظر

Preview Xhorse Condor XC-Mini Plus II Key Cutter

2018 new Xhorse Condor XC-Mini Plus (Condor XC-Mini II) key cutting machine will be released in the next 2 months.

Parameter

Working Temperature 0-50

Humidity: 10-90%

Working Voltage: 90-264V/AC

Input Frequency: 47-63Hz

Package Dimension: 450 x450x350mm

Machine Dimension: 265 x362x301mm

Net Weight: 18kg

Gross Weight: 22.9kg

Power: 200W

USB port: 2.0

LED Display:

1024×600

Motor Rotation Speed: 9000rpm

Clamps:

M1 and M2 in default, M3 and M4 clamps optional

Update: Online (same database as Condor XC-Mini)

Condor XC-Mini Plus Preview:

Outlook:

with flexible screen display which is convenient than Condor XC-Mini

Look inside parts:

www.vvdishop.com

condor xc-mini condor xc-mini plus

Emily سه‌شنبه 1 خرداد 1397 ساعت 08:49

0 نظر

BMW FRM 2M25J 3M25J 9S12XEQ384 Pinout to VVDI Prog

Here’s the guide to restore the original eeprom from Dflash to repair BMW E-series FRM (BMW Footwell Module) module by using Xhorse VVDI Prog programmer.

Note:

VVDI Prog adds FRM-E-SERIES-XEQ384 and FRM-F-SERIES-XET512 read & write options since version 4.6.8 (check pinout connection to VVDI Prog in the end of the post).

Here takes an example on BMW E-series E71

Step 1: Read Dflash

Connect FRM module with VVDI-prog

Open VVDIprog software

Select MCU->Motorola -MC9S12->9S12XEQ384 unsecured
