How to use VVDI2 to add key for Passat 2013 NEC Dash

Here is the guide to use Xhorse VVDI2 VAG key programmer to add key for Passat 2013 with VDO NEC+24C64 dashboard by OBD.

VVDI2 adds Passat 2013 Key Guide:

Go to VVDI2 software-> select VW car brand

Select Key Learn->4th Immobilizer system-VW/Skoda/Seat->Auto detect type
VVDI2 read VIN ECU and dash type: NEC+24C64

Click on Diagnosis

Click on Read EEPROM/FLASH
Select Read eeprom, click on Next

Turn ignition to ON position (If it is smart key, turn ignition OFF then turn it ON)

Dash instrument screen is in black, it is normal

Follow VVDI2 key programmer prompts:

1.Dashboard is in black, complete following steps to activate the dash:

2.Read and save eeprom data

3.Read and save IMMO data

4.Generate a dealer key (if has working key and does not need to add a key, skip to Step 7)

5. Reset dash

6.Key learning from immo data

7. Other functions

Reading eeprom data
Dave eeprom data

Read Immobilizer data
Save immo data

Click on Generate Dealer Key

Choose car manufacture->VW

Select Prepare normal dealer key

Insert car key into vvdi2 VW

click Next
confirm YES to generate VW normal dealer key

Generate dealer key success

all preclude done

Reset dash

Reset success. Dash activated.

Select Add key

(Make sure you have backup both eeprom and immo data)

Select 2nd option to do key learning and enter key numbers to to learned
click on Next

Turn ignition to ON position (If it is smart key, turn ignition OFF then turn it ON)
Confirm if it is smart key

If the dash display 1-2, insert next key into VVDI2’s coil

Insert second key within 5 seconds, turn ignition ON for 2 seconds, dash displays 2-2

Key Learning success

Start engine with the new key.

Done!

www.vvdishop.com

http://blog.vvdishop.com/vvdi2-vag-add-key-for-passat-2013-by-obd/

VVDI2 VAG Audi Key Programming List by OBD

Questions before starting:

Now Xhorse VVDI2 VAGid48 is not ready. so i can’t add key passat b6 or any other vag key with id48 chip?
It programs passat b6 b7 or other id48 cars by obd?

Solution:

Not all possible over obd. Some need read out bcm2, some of them need read out with programmer, like vvdi prog or other.

Some newer Passat with ECU EDC17, if you have condor key cutting machine and with working key,

you can directly do by OBD get 6 cs and use working key get the 7th bytes cs.

If without condor, you should remove the comfort module get the eeprom,unencrypt the cs and pin from EDC17.

Some old model passat with old ECU edc16 ,yes you can by OBD but you must have working key for calculation last two CS No.  No need condor authorization for this , condor authorization is only for calculation PIN CS from edc17.

Customer working experience:

Vvdi2 does passat by obd but not on 1.6tdi with pcr, I have done 2012 caddy by obd with it, f10 key by read mcu in cas4 with vvdi prog and made key with vvdi2 , I have made keys also with the key tool, I have done passat from ccm also and some other vag also.

Full key programming car list which vvdi2 full does by obd.

look the picture:

Credit to darox2005 in MH forum.

http://blog.vvdishop.com/vvdi2-vag-audi-full-key-programming-car-list-by-obd/

Mercedes Benz ECU test Cable DIY and Full Pinouts

This is the DIY guide for you to make Mercedes-Benz ECU test adapters on your own.

MB test cable for W202 W208 W210

MB ECU test cable for W203 W463 W639

Mercedes test cable for W204 W207 W212

MB ECU test cable for W212 W246 W166

Mercedes ECU test cable for W215 W220 W230

Mercedes-benz ecu test cable for W221

Mercedes ECU test cable for W221

Mercedes Test cable for W639

MB ESL/ELV test cable for W204 W207 W212

MB Test cable for W906

MB Test cable for W164

Mercedes test cable for W166 W246

Mercedes ecu test cable for W164

If it’s not easy for you to make Mercedes test cables on your own, you can spend some money on it. There are MB ECU test cables available in the market; technicians working for vvdishop.com tested it’s functionality.

Source: http://www.vvdishop.com/wholesale/benz-ecu-test-adaptor.html

The test cables above have been tested with

Ktag programmer

Kess v2 master

MB KEY OBD2

VVDI MB BGA Tool VVDI2

NEC57

http://blog.vvdishop.com/build-mercedes-ecu-test-cables-yourself/

Xhorse Remote Key Type List for VVDI key Tool

Here is the Xhorse VVDI Key Tool remote generator different remote keys price list fromvvdishop.com.

XHORSE REMOTE LIST AND NEW REMOTE PART NUMBERS.
For VVDI KEY TOOL only.

XK0 series wire remote with different style but same function, without immobilize transponder, work together with TP, support nearly 500 common vehicle types.

XKN series wireless remote with different type but same function, built-in immobilize transponder 11 12 36 42 44 46 47 etc, one support all type.

XK010700 special support for 786MHz.

Pack:　10pcs/lot (Do not sell single piece)

VVDI Key Tool Remote Keys Price List:

Series                                       Type                          Price: USD, 10pcs/lot (not including shipping cost)

X001-02		65USD
X001-03		65USD
X001-04		65USD
X001-05		65USD
X001-06		65USD
Ferrari type (white)  Remote (english version)(with key slot)		53USD
Ferrari type (Red)    Remote (english version)(with key slot)		53USD
X001-786		56USD
X001-01		56USD
X002		56USD
X003		56USD
X004		68USD
X007		56USD
X008		70USD
X013		56USD
XN002		90USD
XN004		90USD
XN008		90USD

Note: VVDI key tool remote keys Chinese version cannot be used with VVDI key tool English version (CH-CH, EN-EN).

English remote now is not yet available. Detail information, please contact:

Skype: VVDIfactory.com
Whatsapp: [phone]
Email: [e-mail]

http://blog.vvdishop.com/xhorse-vvdi-key-tool-remote-keys-price-list/

Mercedes W164 ISM Renew with VVDI MB Mercedes

Xhorse VVDI MB BGA Tool is able to renew Mercedes ECU, gearbox and ISM. Here is the example on renewing W164 ISM. Online Password calculation is required.

Well connect VVDI MB with ECU and laptop via cables

Select Renew ECU/Gearbox Function

Select Module: ISM

Click on Read to read ISM info.

Initialized:Yes

TP cleared: Yes

Personalized: Yes

Activated: Yes

Calculate password from server

Password is calculated, click on Renew

Click on Read button

select ISM

Renew in progress

Click on Read again

Initialized:Yes

TP cleared: Yes

Personalized: No

Activated: No

ISM is virgin.

VVDI Mercedes Renew ISM success!!!

Ps. Mercedes W203 sim4lke ecu renew by VVDI MB Tool
