Xhose VVDI نرم افزار برنامه نویس اصلی و سخت افزارWhere to buy Xhorse VVDI key Tool 4D 4C chips
original 4D 4C car key copy chips for Xhorse VVDI Key Tool remote maker are available in vvdishop.com.
Xhorse Condor Mini V4.0.1 Software for both KM02 KM03
VVDIshop.com has provided Condor XC-Mini key cutting machine V4.0.1 update tool download for S/N KM03 in May,2017. Now new update tool 4.0.1 for both SN KM02 and KM03 is released on 16-06-2017.
——————————————
+Add universal key decode function
+Add M2-D function
+Add motor sensor testing function
*Modify probe/cutter detection
*Fix machine may crash error problem
*Fix HU49 key decode error
*Fix HU66 cutting speed issue
*Fix BW6 cutting error
*Fix TBE1 cutting error
Notes:
1.New update for both SN KM02/KM03 machines
2.New function:Main Interface-Key Duplication-Universal Type
3.Universal Type support decode/cutting parts of home & vehicle keys
4.Please keep the whole key clean and conductivity good(ensure without dust/oil)
5.For one side key(thickness of whole key usually 1.5mm or 2.00mm) please add a shim/business card under the key,ensure the whole key thickness should more than 3mm
How to use VVDI Key Tool to Unlock OEM Remotes
Xhorse VVDI Key Tool remote generator Unlock remote key in test
Features:
- Remote Generation: convert universal blank remotes into remotes that you can program into your customer’s vehicles. Add the blade and chip to complete, then program into the vehicle the same way you would the OEM remote. REDUCE YOUR INVENTORY!
- Remote Testing: confirms your remote is working and identifies type and frequency. Supports 27-900 MHz for frequency test, 300-450 MHz for power test.
- Transponder Identification
- Transponder Generation (coming soon!)
- Transponder Cloning (coming soon!)
- Remote Unlocking (coming soon!–may involve an addition cost)
How to use VVDI2 to add key for Passat 2013 NEC Dash
Here is the guide to use Xhorse VVDI2 VAG key programmer to add key for Passat 2013 with VDO NEC+24C64 dashboard by OBD.
VVDI2 adds Passat 2013 Key Guide:
Go to VVDI2 software-> select VW car brand
Select Key Learn->4th Immobilizer system-VW/Skoda/Seat->Auto detect type
VVDI2 read VIN ECU and dash type: NEC+24C64
Click on Diagnosis
Click on Read EEPROM/FLASH
Select Read eeprom, click on Next
Turn ignition to ON position (If it is smart key, turn ignition OFF then turn it ON)
Dash instrument screen is in black, it is normal
Follow VVDI2 key programmer prompts:
1.Dashboard is in black, complete following steps to activate the dash:
2.Read and save eeprom data
3.Read and save IMMO data
4.Generate a dealer key (if has working key and does not need to add a key, skip to Step 7)
5. Reset dash
6.Key learning from immo data
7. Other functions
Reading eeprom data
Dave eeprom data
Read Immobilizer data
Save immo data
Click on Generate Dealer Key
Choose car manufacture->VW
Select Prepare normal dealer key
Insert car key into vvdi2 VW
click Next
confirm YES to generate VW normal dealer key
Generate dealer key success
all preclude done
Reset dash
Reset success. Dash activated.
Select Add key
(Make sure you have backup both eeprom and immo data)
Select 2nd option to do key learning and enter key numbers to to learned
click on Next
Turn ignition to ON position (If it is smart key, turn ignition OFF then turn it ON)
Confirm if it is smart key
If the dash display 1-2, insert next key into VVDI2’s coil
Insert second key within 5 seconds, turn ignition ON for 2 seconds, dash displays 2-2
Key Learning success
Start engine with the new key.
Done!
http://blog.vvdishop.com/vvdi2-vag-add-key-for-passat-2013-by-obd/
VVDI2 VAG Audi Key Programming List by OBD
Questions before starting:
Now Xhorse VVDI2 VAGid48 is not ready. so i can’t add key passat b6 or any other vag key with id48 chip?
It programs passat b6 b7 or other id48 cars by obd?
Solution:
Not all possible over obd. Some need read out bcm2, some of them need read out with programmer, like vvdi prog or other.
Some newer Passat with ECU EDC17, if you have condor key cutting machine and with working key,
you can directly do by OBD get 6 cs and use working key get the 7th bytes cs.
If without condor, you should remove the comfort module get the eeprom,unencrypt the cs and pin from EDC17.
Some old model passat with old ECU edc16 ,yes you can by OBD but you must have working key for calculation last two CS No. No need condor authorization for this , condor authorization is only for calculation PIN CS from edc17.
Customer working experience:
Vvdi2 does passat by obd but not on 1.6tdi with pcr, I have done 2012 caddy by obd with it, f10 key by read mcu in cas4 with vvdi prog and made key with vvdi2 , I have made keys also with the key tool, I have done passat from ccm also and some other vag also.
Full key programming car list which vvdi2 full does by obd.
look the picture:
Credit to darox2005 in MH forum.
http://blog.vvdishop.com/vvdi2-vag-audi-full-key-programming-car-list-by-obd/
