How to change Seat Leon III MQB mileage with VVDI2

New test feedback: done Seat Leon 3 / Golf 7 MQB  mileage correction with Xhorse VVDI2 VAG 5.2.1 success.

Open VVDI2 software

Select Seat->Key Learn->Immobilizer of instrument platform MQB-> instrument  with NEC+24C64 MQB key

Click read data, auto detect vehicle type etc

Click on Read KM

Current mileage: 500KM

check odometer on instrument, it is the same

Enter the mileage you desired:118090KM

Click on Write KM

Accept VVDI2 warning messages

The dashboard indicators go off during the procedure, it is normal.

Success.

VVDI2 Seat Leon 3 MQB odometer correction is done.

http://www.vvdishop.com/wholesale/vvdi2-copy-id48-transponder-authorization.html

How to use VVDI MB to calculate W204 key password from EIS

Here’s the step-by-step guide to calculate MB W204 EIS all keys lost key password using VVDI MB BGA Tool and power adapter in 20 minutes.

Connect W204 EIS using VVDI MB EIS cables

now follow the steps
Open VVDI MB software

Select EIS Tools->Read EIS data->Save EIS data

Save eeprom bin file and HC05 format file

Select Password Calculation

Tick lost all working key

Select chassis W204

Click on Data Acquisition

1. This opeation need about 18 minutes. DON’T perform this opeartion on the car!!!
2. Connect EIS with correct able before continue
3. Don’t connect ESL to cable.

Now we connect the adapter

Connect MB power adapter (VVDI MB speed adapter) with VVDI MB

Click YES to continue

Please connect 12V to MB power adapter! DON’T provide 12V power to EIS

Remove 12V power adapter from EIS cable and connect it to MB power adapter

Click YES

Connect EIS with correct cable on the bench, don’t connect ESL.
Connect “device OBD line” to cable OBD head. Attention: No car OBD

Press OK after confirm

Connect “IR adapter” to VVDI MB tool before press OK

Press OK
Now you have to wait 18-25 minutes

Save pass dat. file

Acquisition finished, update the saved data with “Upload data” for password

Upload success. Quene number 1. require about 1 minute to finish

Wait about 2 minutes and then press Query Result

Calculate password success. Paste the pass

Remove the adapter and then connect 12V cable to EIS cable

Select EIS Tools->Read EIS data

Paste key pass

Save and replaced EIS data

Success.

www.vvdishop.com

http://blog.vvdishop.com/calculate-w204-eis-password-with-vvdi-mb-and-power-adapter/

Xhrose VVDI2 V5.2.0 Enbales MQB Immo Function

Xhorse VVDI2 key programmer software released to V5.2.0 on Jan, 19th, 2018. If you have ID48 96bit license, you can use MQB KM and Immo function.

VVDI2 V5.2.0 Update Feature

************************************************* *********************
*** 2018-01-19
*** Require firmware V5.2.0
************************************************* *********************
===== VAG V5.2.0 =====
1. Improvement MQB NEC35xx immobilizer/KM function, support following cars:
Audi A3/S3 2014+
Audi Q2
VW Golf7
VW Polo(MQB)
VW Tiguan II
VW Touran II
VW crafter 2017+
VW Passat B8 without virtual cockpit
Skoda Octavia III 2014.07+
Skoda Rapid 2015.06+
Skoda Kodiaq
Skoda Superb III
Seat Ibiza/Ateca/Toledo 2015.06+Attention 1: This type only support cars with cluster Continental/VDO. JCI type and virtual cockpit was not include
Attention 2: Improvement for prepare dealer key: support original blank key and MQB key made by VVDI
Attention 3: MQB Immobilizer function require extra license. Customer who have copy 48 (96 bit) license will get MQB license for free
Attention 4: Improvement for key learn function
Attention 5: Bugfix for access some MQB instrument
2. Improvement for autodetct in IMMO4 system
3. Add spanish language
4. Bugfix

===== BMW V5.2.0 =====
1. Improvement for read ISN from MSx8x ECU, require VVDI2 database file verison V1.0.0
2. Improvement for load MEV17xx EEPROM dump
3. Support change second hand FEM/BDC ISN and make original key working
4. Add spanish language
5. Bugfix

===== Porsche V5.2.0 =====
1. Add spanish language
2. Bugfix

===== PSA V5.2.0 =====
1. Add spanish language
2. Bugfix

===== Transponder Programmer V5.2.0 =====
1. Bugfix for update remote database
2. Bugfix for save points
3. Immobilizer data tool: bugfix for Fiat Ducato 93C56
4. Add spanish language
5. Bugfix

===== J2534 V5.2.0 =====
1. Add spanish language
2. Bugfix

===== Online Upate Tool V5.2.0 =====
1. Add spanish language
2. Bugfix

===== Quick Start V5.2.0 =====
1. Bugfix

Free download VVDI2 V5.2.0 software

https://mega.nz/#!u5xBhTSZ!m93DbBh0ZudhcGavQv5o70olqE55jZxzAfieolBDKzI

Xhorse VVDI2 V5.1.0 Adds VAG MQB Immo License

Xhorse VVDI2 key programmer software released to V5.1.0 on 18/01/2010.

*** 2018-01-18
*** Require firmware V5.1.0
************************************************* *********************
===== VAG V5.1.0 =====
1. Improvement MQB NEC35xx immoblizer/KM function, support following cars:
Audi A3/S3 2014+
Audi Q2
VW Golf7
VW Polo(MQB)
VW Tiguan II
VW Touran II
VW crafter 2017+
VW Passat B8 without virtual cockpit
Skoda Octavia III 2014.07+
Skoda Rapid 2015.06+
Skoda Kodiaq
Skoda Superb III
Seat Ibiza/Ateca/Toledo 2015.06+Attention 1: This type only support cars with cluster Continental/VDO. JCI type and virtual cockpit was not includ
Attention 2: MQB Immobilizer function support original blank key and MQB key made by VVDI2
Attention 3: part of original blank key not support write data
Attention 4: MQB Immobilizer function require extra license. Customer who have copy 48 (96 bit) license will get MQB license for free
2. Improvement for autodetct in IMMO4 system
3. Add Spanish language
4. Bugfix

===== BMW V5.1.0 =====
1. Improvement for read ISN from MSx8x ECU, require VVDI2 database file verison V1.0.0
2. Improvement for load MEV17xx EEPROM dump
3. Support change second hand FEM/BDC ISN and make original key working
4. Add spanish language
5. Bugfix

===== Porsche V5.1.0 =====
1. Add spanish language
2. Bugfix

===== PSA V5.1.0 =====
1. Add spanish language
2. Bugfix

===== Transponder Programmer V5.1.0 =====
1. Bugfix for update remote database
2. Bugfix for save points
3. Immobilizer data tool: bugfix for Fiat Ducato 93C56
4. Add spanish language
5. Bugfix

===== J2534 V5.1.0 =====
1. Add spanish language
2. Bugfix

===== Online Upate Tool V5.1.0 =====
1. Add spanish language
2. Bugfix

===== Quick Start V5.1.0 =====
1. Bugfix

Free download XHorse vvdi2 v5.1.0 software

https://mega.nz/#!PoJBSBKD!nn1ai-JfcoqAM4hbnitabziaSWY-5vkz-1erx4gj7VY

http://blog.vvdishop.com/xhorse-vvdi2-software-update-to-v5-1-0/

How to Program BMW EWS4 key with VVDI Prog EWS4 adapter

Here’s little guide to make BMW X3 EWS4 transponder key with new VVDI PROG EWS4 adapter and VVDI2 key programmer.

Step 1: Read EWS4 Eeprom by VVDI Prog

Remove dash

Take out EWS4 immo box

Disassemble the EWS4 module

Put EWS4 module in the VVDI PROG EWS4 adapter and lock it

Connect VVDI PROG with EWS4 adapter, then connect vvdi programmer with computer with USB cable

Open VVDI Prog software

Select Type 4th Immo, BMW and chip EWS4 adapter

Check connection diagram

Click Read ID to identify the Micro and make sure that the connection is correct to avoid possible failures.

Chip initialization, make sure all chip type matches

It has to match any of them, if not, it is connected badly

Click Read to read eeprom data and save it

Step 2: Program EWS4 key by VVDI2 BMW

Open VVDI2 software

Select Transponder Programmer

Select Auto detect Transponder: PCF7935

Choose Immobilizer Data Tool function

Select region, vehicle make and immo type

Click Load EEPROM Dump

select an unused key position and press Make Dealer Key

Prepare dealer key success. Now the key can start engine.

Reinstall EWS4 module back to car.

Test the new key, remote works, car starts

Done.
