Xhorse Condor XC-mini Plus Feedback

Thanks to the genuine users of Condor XC mini plus & Dolphin feedback.

Condor XC mini ii review 1:

I did a 2010 Suzuki alto today with condor, hu133r kd blade worked perfect.

Condor XC mini plus review 2:

Decoded HU100 key today with Condor XC mini plus, sec e9 can not. Condor cut HU100 wrong, to wide track and to much to the left. Put in biting in sec e9, cut perfekt key, but can not decode.

Condor XC mini plus review 3:

Peugeot 107 is va6

Va2T on 107 up to 2013.
And I done one today. Decoded and cut perfectly.
Va6 decode by eye and enter manually on va2eh2 card.
I only see these on citroen DS and renaults in my day to day jobs really.

Condor XC mini plus review 4:

I decoded few of the older keys (HU64), so no problems there. Then took picture of the decoding and manually wrote the coding on HU64-3 and were no problems.

Condor XC mini plus review 5:

Dolphin and condor mini both use the same database

Condor XC mini plus review 6:

At first, Can’t cut Volvo HU56R, always overcut…2.5 mm cutter….

First, I was told ” you must set cutting -0,35 and all ok.”

Like this

Condor mini plus review 7:

The one on top is the original.
After cutting a key, that would not work, i calibrated the condor.
Cut a new key, showing in the picture.
Checked it with a caliper. Seems perfect.
But not opening the lock.
Org opens lock smooth.
Could it be the shoulder, shifting the blade of center?
Car is no longer in my shop, and this key, i send to customer.
what am I missing here, this key should work?!?

Reply: the hu64 has 3 type of the tip , the angle of those 3 types are different , the picture you put what above is hu64-3 , downside is hu64-2 , you need to choose correct angel of it , the shoulder is of the blade will effect nothing about open the lock ,

Condor XC mini plus review 8:

Condor mini PLUS contains no battery inside, need to connect with power cable.

Condor Dolphin review:
Decode and cut HU64 old style blade: Result Success
Use bitting, and write into new style HU64-3: Result Success

This is the first time experienced that this actually works.
This has always failed in some way earlier.
Not sure if there was some update, which did the trick.

This door lock was in very good condition. It was working really smooth. Not adding any lubrication.

1,5mm which machine says is recommended.

Program 2011 Audi Q7 All Keys Lost by VVDI2 VVDI Prog

Need feedback:

Audi Q7 2011 all key lost .
Using vvdi prog and vvdi2
1-Reading EZS eeprom 32KB using vvdi prog (0L01Y).
2-On vvdi2 choose key position 1.
3- prepare Dealer key.
4- writing new eeprom dump to EZS using vvdiprog .

this model all key lost can’t do through obd2, need to remove ecu
Car start success

Read Nissan Pathfinder Pin with VVDI2 by Dump?

Needed pincode for NISSAN PATHFINDER.

This is the dump from the car read with xprog but I couldn’t read it with vvdiprog.

https://mega.nz/#!IUJxXSQR!fVG8vccj5mksAhyeMTdU7IRsEFXVP5j7vIP3-MkzREI

Suggestion:

Just make transponder with this dump no need for pin code

here put that file in tms and put everything in place put key with transponder and turn ign on for 5 second 3 times
then start car

https://mega.nz/#!URQVhaQR!Lx0WFTFx9alkopUCM2lNG_fUo-txa_xbPP56clKJJW0

Xhorse vvdi2: VVDI2 Ver 6.6.0 can now recognize the dump file.

Tango software: yes

Post transponder data 4d60 using EFFI

www.vvdishop.com

How to Update Condor Dolphin XP005 via Upgrade Kit?

How-to: update Xhorse Dolphin XP005 key cutting machine software/firmware and install driver using Upgrade Kit.

Preparation:

Download Xhorse Upgrade Kit

Download Dolphin XP005 Windows x32 x64 Drivers

Download Upgrade Kit and install setup

Update the Upgrade kit to the latest version

Connect Dolphin key machine with computer via USB cable

Turn on the Dolphin XP005 machine and connect it with the computer, it will show the BIOS on the screen of Dolphin as below,

Run the upgrade kit and choose ‘Find Device’, it will be show a small window , choose ‘Yes’ and will guide to install the driver

Choose the correct driver according to the machine as below, make sure you are shut down all protection before you install the driver, especially for windows 10 system

You need to download and install Windows driver for Xhorse Dolphin

After the driver has been installed, run the ‘Upgrade kit’ and choose ‘Find Device’ again, to see if you can see the device serial number and firmware version, do not chose ‘Upgrade’ until it you can see that , because if you can’t find device ,which means the driver is not been installed, and the machine will be blocked if you update it without driver

Press “Upgrade” and wait till the procedure completed

Update succeed.



www.vvdishop.com

Will VVDI MB add FBS4 keys?

The answer is only dealer can add FBS4 keys. VVDI MB tool V5.0.2 can disable FBS4 key, CGDI MB can read FBS4 keys.

1. Since VVDI MB V5.0.1, it adds FBS4 disable key function(Special function->FBS4 disable key)- Support

W166/W205/W213/W218/W222/W246 type.

2. CGDI MB can read FBS4 keys:

CGDI can read FBS4 keys and knows if it’s in a working status or if the key is damaged;

That is CGDI can’t make calculation for FBS4 . Only Read to know the status.

FBS4 applicable models: April 2013 to Present, Model W212; July 2013 to Present, Models 166, 207, V212; September 2014 to Present, Model 218; November 2014 to Present, Models 117, 156; April 2015 to Present, Model 172; MY-AII, Models 205, 217, 218, 222, 231.

MY2013, Model 166 with Code 803, Models 207 and 212 with Code 804.

Besides, you can check SA Codes on vehicle data card or use any suitable online vin decoder to see SA codes related to your vin. You are looking for the presence of SA code 803 or 804, depending on the Model this means vehicle is FBS4 related.



www.vvdishop.com
